Question 1

Introduction

Accepted Answer

Welcome to Chamevo!

Chamevo is a powerful product customization tool for WordPress and WooCommerce. It allows your customers to personalize products directly on your store’s frontend with live previews and an intuitive interface. Whether it’s apparel, accessories, or printed goods, Chamevo integrates seamlessly with WooCommerce to provide flexible, interactive product options.

${frame}Interactive Guide

Installing & Updating Chamevo

1. Purchase & Download

Available exclusively via the Customer Portal (no longer on CodeCanyon).
After purchase, download the plugin anytime from your account.

2. Install

Upload the plugin via your WordPress Admin → Plugins → Add New → Upload.
Activate the plugin.

3. Activate

Enter your license key in the WordPress admin panel.
Once activated, updates are delivered automatically in your dashboard.

Quick Setup

Building Your First Customizable Product

Step 1: Create a Chamevo Product

Go to Product Section In Chamevo Dashboard
Add +New Product or Use Template Library.
Enter a product title
Optionally:

Add a thumbnail image
Assign categories (or create a new one)

→ Read full guide

Step 2: Add Views

Views represent differ

Question 2

Build Your Customizable Product

Accepted Answer

Chamevo Products are the customizable items you create using the Product Builder. They function like any other WooCommerce product but offer much greater flexibility.

Each Chamevo Product can have multiple views (e.g. front and back of a t-shirt).
Products can include options such as color, size, or design variations.

${frame}Interactive Demo

Creating a New Product

Click New to add a new product.
Enter a product title in the popup window.
The new product will now appear in the product list.
(Optional) Assign a thumbnail by clicking the empty image box next to the title.
(Optional) Assign the product to a category:

Click Manage Categories.
If no category exists, click Add New Category and enter a title.
Select your product in the list.

| Each Chamevo Product can be assigned to multiple categories.

Categories also include icons for:

Editing the title
Filtering products by category
Deleting the category

Adding Views to a Product

Every product must have at least one view, representing an angle or variation (e.g. front/back of a shirt).

Click the Add View (+) icon to add a new view.
Enter a title for the view.
Assign a **thum

Question 3

Print Profiles and Print Areas

Accepted Answer

|| Chamevo gives you two powerful tools to control product customization: Print Areas (where designs go) and Print Profiles (how customers can design).

This guide gives you the big picture of how Print Areas and Print Profiles work together. For detailed workflows see the related articles here and here for more information.

${frame}Interactive Demo

Print Areas

Print Areas define the regions of a product where your customers can place designs. Use them for multi-sided products (front/back cards, packaging, brochures) or for products with custom shapes (stickers, labels).

Key features:

Add multiple print areas per view (front, back, sides, etc.).
See the active area with a checkmark icon.
Zoom in/out for precision editing.
Use SVG masks for custom shapes.
Automatic bleed, crop marks, and correct sizing.
Elements stay inside their area with boundary controls.

How to create a Print Area (Quick Start):

Go to Chamevo → Products
Click on Layers Icon to expand views
Select Edit In Product builder

Click Print Settings to open new menu on right hand side.

![](

Question 4

Connect WooCommerce Store

Accepted Answer

Customizable products can be linked directly to WooCommerce products, allowing your customers to personalize items before purchasing.

|| You must first create a customizable product in the backend. If you haven’t, check the separate tutorial on how to do this.)

${frame}Interactive Demo

Creating a WooCommerce Product

Navigate to your WordPress Admin Dashboard and in WooCommerce Section Click on Add New product.
Add Product Name
Add Product Description
Add Pricing

Customizable Product Meta Box

A Customizable Product meta box will appear on the right-hand side of the editor.

If it doesn’t appear, click the Settings (⚙️) icon in the top-right corner.
From the meta box, you can: Assign one or more categories or select individual products.

Publishing & Preview

Once configuration is complete:

Click Publish.

Switch to the frontend of your store to

Question 5

Setting Print Areas for Export

Accepted Answer

With Print Areas, you can:

Add multiple print areas per view (e.g., multiple zones on the same T-shirt).
Easily switch and zoom between areas for detailed editing.
Apply custom shapes using SVG masks for unique print regions.
Ensure professional print preparation with bleed, crop marks, and precise alignment.
Keep layouts clean and accurate with automatic element clipping.

In this guide, we’ll set up a customizable T-shirt with two print areas on the front and one on the back to showcase these features.

${frame}Interactive Demo

Example: Creating a T-Shirt with 2 Print Areas (Logo And Body)

Step 1. Open Print Areas Menu

In the Admin Dashboard, click on Products from the left-hand menu.
Click on the Layers icon for the T-shirt product.
Select Edit in Product Builder.

Step 2. Open the Print Areas Menu and Add Print Areas

On the right-hand side, click the Print Areas button to open the print area menu.
Name your Print Area.
On the front of the T-shirt, create two print areas by naming the Print Areas, Choosing Size and Bleed.
You can adjust Mask of the Print Area in after creating it.

![](https://storage.crisp.chat/users/helpdesk/w

Question 6

Enabling Chamevo For Any Page

Accepted Answer

|| Chamevo isn’t limited to WooCommerce products — you can also embed it directly into posts or pages using shortcodes. || Shortcodes are not necessary for WooCommerce products.

${frame}Interactive Demo

Adding Shortcodes

Create a new post/page or select an existing one.
Insert the following shortcodes:

[chamevo] → Loads the product designer.

[chamevo_form] → Adds the form required to send the customized product to the site owner.

Chamevo Meta Box

A Chamevo meta box will appear on the right-hand side of the editor.
If it doesn’t appear, click the Settings (⚙️) icon in the top-right corner.
From the meta box you can:
Add single Chamevo Products, or Add product categories via the Source Type option.
Select products or categories from the dropdown.
For mobile optimization, you can assign different products for smaller screens.

Publishing & Preview

Once you’ve finished configuration:

Click Publish
Preview the page/post to see the designer in action.

Customizing the Layout

You can further customize the product page by adding shortcodes for:

Action buttons
Modules
Other designer element
